Mini cement ball millis a key equipment for regrinding.
It is widely used for mining ore, the cement, the silicate product, new type building material, fire-proof material, chemical fertilizer, black and non-ferrous metal, glass, ceramics and etc.
The Mini cement ball millcan grind ore or other materials that can be grinded either by wet process or by dry process.
1. This type of Mini cement ball millis a kind of traditional 1830x7000 dry ball mill, with rolling bearings (Babbitt metal bearing bushing seat)
2. Simple structure, and split installation.
3. It is easy to lift it while installing and maintaining.
4. Its feeders are classified into two types: combined feeder and cylinder feeder.
5. Since the Mini cement ball millare classified into two types: grate ball mill and overflow ball mill, please specify the type.
1. Shell of super thick steel plate and heavy duty design.
2. Lining plate of high manganese steel allows for longer service life.
3. Bearing foundation of high quality babbitt metal ensures the optimum performance.
4. High strength and high precision pinion gear and bull gear.
| ball mill | Rotational speed (r/min) | Ball weight (t ) | Feeding size (mm) | Discharging Size (mm) | Capacity (t/h) | Motor power (Kw) | weight (t) |
| Φ900*1800 | 38 | 1.5 | <20 | 0.075-0.89 | 0.65-2 | 18.5 | 3.6 |
| Φ900*2100 | 38 | 1.3-1.4 | <15 | 0.075-0.83 | 0.7-3.5 | 18.5 | 3.9 |
| Φ900*3000 | 38 | 2.7 | <20 | 0.075-0.89 | 1.1-3.5 | 22 | 4.5 |
| Φ1200*2400 | 32 | 3.8 | <25 | 0.075-0.6 | 1.5-4.8 | 30 | 11.5 |
| Φ1200*2800 | 32 | 3.3-3.5 | <25 | 0.075-0.6 | 2-6 | 30 | 13 |
| Φ1200*4500 | 32 | 7 | <25 | 0.074-0.4 | 1.6-5.8 | 45 | 13.8 |
| Φ1500*3000 | 27 | 8 | <25 | 0.074-0.4 | 2-5 | 75 | 17 |
| Φ1500*3500 | 27 | 6.75-5.4 | <25 | 0.074-0.4 | 3-7 | 75 | 17.5 |
| Φ1500*4500 | 27 | 14 | <25 | 0.074-0.4 | 3.5-12 | 110 | 21 |
| Φ1500*5700 | 27 | 15 | <25 | 0.074-0.4 | 3.5-8 | 115 | 24.7 |
| Φ1830*3000 | 24 | 18 | <25 | 0.074-0.4 | 4-10 | 130 | 28 |
| Φ1800*3600 | 24 | 10.6-11.35 | <25 | 0.074-0.4 | 5-22 | 130 | 33.5 |
| Φ1830*7000 | 24 | 25 | <25 | 0.074-0.4 | 7.5-17 | 210 | 36 |
| Φ2100*3600 | 22 | 14-15.2 | <25 | 0.074-0.4 | 15-36 | 370 | 46.8 |
| Φ2200*5500 | 21 | 30 | <25 | 0.074-0.4 | 10-22 | 210 | 48.5 |
| Φ2200*6500 | 21 | 31 | <25 | 0.074-0.4 | 14-26 | 380 | 52.8 |
| Φ2200*7500 | 21 | 33 | <25 | 0.074-0.4 | 16-29 | 380 | 56 |
| Φ2400*3000 | 20.6 | 15.5-16.6 | <25 | 0.074-0.4 | 22-44 | 245 | 59 |
| Φ2400*4500 | 21 | 30 | <25 | 0.074-0.4 | 8.5-60 | 380 | 65 |
| Φ2700*3600 | 20.6 | 39 | <25 | 0.074-0.4 | 12-70 | 400 | 91.3 |
| Φ2700*4000 | 20.7 | 40 | <25 | 0.074-0.4 | 12-80 | 400 | 94 |
| Φ2700*4500 | 20.7 | 48 | <25 | 0.074-0.4 | 12-90 | 430 | 102 |
| Φ3200*4500 | 18 | 65 | <25 | 0.075-0.4 | according to craftwork conditions | 800 | 137 |
FAQ
A; we can send our technician to your work site to make basement construction.
B; we can send our workers to your work site to make the plant installation.
C; we guarantee our kilns can produce the qualified products by your requirements.
D; we can offer all drawings of the plant.
E; we guarantee the best whole life after-sales.
Welcome for your inquire and visit!
Minimum order: 1 Units
Payment terms, specifications, and order details are confirmed before preparation begins.
Lead time will be confirmed with your quotation.
Packaging details are available on request.
Final packing, freight, and delivery dates are confirmed before dispatch.
